Mount Top Box Plate To Grab Rail On 850 ?

Started by JMC , Mar 04 2019 02:20 pm

  • Please log in to reply
12 replies to this topic

#1 JMC

JMC

    Carpe groupie

  • Member
  • PipPip
  • 259 posts
  • Location:Ireland
  • TDM model: 2000

Posted 04 March 2019 - 02:20 pm

So anyone do it ? fixed directly to grab rail that is....

Got any pics before I attempt this madness :D

I'd rather not drill the rack btw



ok so I've done a search and seen a few ideas so will attempt this week but would still appreciate any pics :)


Edited by JMC, 04 March 2019 - 02:58 pm.
